Parte: Bastidor delantero
DJI Agras T25 — 45 piezas identificadas con su código de parte oficial DJI. Toque un número del diagrama para ver de qué pieza se trata, y abra la ficha para ver precio y compatibilidad.
Pase el cursor sobre un número —o tóquelo— para ver la pieza. También puede recorrer la tabla.
Piezas de este conjunto
| N.º | Código DJI | Repuesto | Nombre técnico | Precio ref. |
|---|---|---|---|---|
| 1 | YC.XC.XX001013 | Cable de Señal del Sensor de Visión Delantera - T25/T50 | Forward Vision Sensor Signal Cable | $20.00 |
| 2 | YC.ST.LL000122 | M25-HC00780040-055020-5103-N | Screw M25-HC00780040-040020-5108-N | $3.00 |
| 3 | BC.AG.SS000671 | Módulo de Visión Delantera - T50 | Forward Vision Sensor Module | $203.40 |
| 4 | YC.ST.LL000226 | Perno M30-HC01450080-100020-5103-Y | M30-HC01450080-100020-5103-Y | $4.00 |
| 5 | YC.JG.MY001038 | Caucho de Silicona Amortiguador - T25/T50 | Damping Silicone Rubber | $4.00 |
| 6 | YC.JG.ZS003455 | Clip de Cable Rf - T25/T25P/T50 | RF Cable Clip | $5.00 |
| 7 | YC.ST.LL000235 | Perno 057030-5103-N T40/T20P | T30-HC00800080-057030-5103-N | $3.39 |
| 8 | YC.WJ.LL000232 | M40-HC01000100-072028-5103-N_01 | M40-HC01000100-072028-5103-N_01 | $3.00 |
| 9 | YC.JG.ZS003425 | Soporte de Cámara FPV - DJI Flycart 30/T25/T50 | FPV Camera Bracket | $40.00 |
| 10 | YC.WJ.LL000232 | M40-HC01000100-072028-5103-N_01 | M40-HC01000100-072028-5103-N_01 | $3.00 |
| 11 | YC.DZ.AA000326 | Antena SDR Delantera - T25/T50 | SDR Antenna (Front) | $25.99 |
| 12 | YC.JG.MY001079 | Guia de Carcasa Frontal - T50 | Front Shell Sealing Stopper | $3.50 |
| 13 | YC.JG.ZS003388 | Carcasa Inferior Delantera - DJI Flycart 30/T25/T50 | Front Shell Bottom Plate | $40.00 |
| 14 | YC.ST.LL000148 | Perno M40-HC01400140-070039-4105-Y | M40-HC01400140-070039-4105-Y | $3.39 |
| 15 | YC.JG.ZS003389 | Cubierta Superior de Carcasa Delantera - DJI Flycart 30/T25/T50 | Top Cover of Front Shell | $20.00 |
| 16 | YC.ST.LL000228 | Perno M20-PC00400040-040010-5103-Y | M20-PC00400040-040010-5103-Y | $3.39 |
| 17 | YC.WJ.L00870 | Tornillos M30-HC060060-55-85 - T30/T10 | Screw M30-HC060060-55-85 | $3.39 |
| 18 | BC.AG.SS000681 | Cámara FPV - T50 | FPV Camera Module | $450.87 |
| 19 | YC.JG.ZS003435 | Brazo Auxiliar - T25/T50 | Auxiliary Arm | $6.00 |
| 20 | BC.AG.SS000682 | Tapa de Lente - T50 | Lens Cap Module | $25.00 |
| 21 | YC.JG.MY000985 | Anillo de Lente - T50 | Lens Cap Sealing Gasket | $4.52 |
| 22 | YC.WJ.L00870 | Tornillos M30-HC060060-55-85 - T30/T10 | Screw M30-HC060060-55-85 | $3.39 |
| 23 | YC.JG.QX003038 | Soporte Sello de la Cámara FPV - T50 | FPV Camera Bracket Supporting Piece | $6.00 |
| 24 | YC.WJ.LL000232 | M40-HC01000100-072028-5103-N_01 | M40-HC01000100-072028-5103-N_01 | $3.00 |
| 25 | YC.ST.LL000122 | M25-HC00780040-055020-5103-N | Screw M25-HC00780040-040020-5108-N | $3.00 |
| 26 | YC.ST.LL000013 | Tornillos M40-HC01400140-070039-0003-Y - T30/T10 | Screw M40-HC01400140-070039-0003-Y | $3.39 |
| 27 | YC.JG.YZ000671 | Soporte de Radar Delantero - T25/T50 | Forward Radar Bracket | $35.00 |
| 28 | YC.ST.LL000226 | Perno M30-HC01450080-100020-5103-Y | M30-HC01450080-100020-5103-Y | $4.00 |
| 29 | YC.JG.MY001038 | Caucho de Silicona Amortiguador - T25/T50 | Damping Silicone Rubber | $4.00 |
| 30 | YC.JG.MY001044 | Sellado Visión Binocular - T50 | Binocular Vision Sensors Sealing Ring | $5.65 |
| 31 | YC.XC.XX001013 | Cable de Señal del Sensor de Visión Delantera - T25/T50 | Forward Vision Sensor Signal Cable | $20.00 |
| 32 | BC.AG.SS000671 | Módulo de Visión Delantera - T50 | Forward Vision Sensor Module (Incl. Signal Cable) | $203.40 |
| 33 | YC.WJ.L00870 | Tornillos M30-HC060060-55-85 - T30/T10 | Screw M30-HC060060-55-85 | $3.39 |
| 34 | YC.JG.ZS003452 | Cubierta Lateral de Brazo - T25/T25P/T50 | Outer Shell Side Cover | $8.00 |
| 35 | YC.JG.ZS003387 | Carcasa Delantera - T25/T50 | Front Shell Module | $45.00 |
| 36 | YC.WJ.L00870 | Tornillos M30-HC060060-55-85 - T30/T10 | Screw M30-HC060060-55-85 | $3.39 |
| 37 | YC.JG.MY001041 | O Ring de Radar - T50 | Radar Sealing Ring | $6.00 |
| 38 | YC.JG.YZ000672 | Base de Radar Delantera - T25/T50 | Forward Radar Base | $30.00 |
| 39 | YC.JG.MY001042 | O Ring Base de Radar - T50 | Radar Base Sealing Ring | $6.00 |
| 40 | BC.AG.SS000939 | Módulo de Radar Frontal - T25/T50 | Forward Radar Module | $1,940.00 |
| 41 | YC.XC.XX001011 | Cable Radar Delantero - T25/T50 | Forward Radar Signal Cable | $20.00 |
| 42 | YC.JG.ZS003493 | Pieza de Soporte Lh del Radar - T25/T50 | Radar Left Supporting Piece | $20.00 |
| 43 | YC.JG.ZS003492 | Pieza de Soporte de Radar (Derecha) | Radar Right Supporting Piece | $12.00 |
| 44 | BC.AG.SS000940 | Módulo de Radar Trasero - T25/T50 | Rear Radar Module | $1,695.00 |
| 45 | YC.XC.XX001012 | Cable de Señal de Radar de Visión Trasera - T25/T50 | Rear Vision Radar Signal Cable | $35.00 |
